Ubiquiti Networks LiteBeam 5AC Gen2
Product Specification
Wind Survivability
- 200 km/h (125 mph)
Wind Loading
- 275 N @ 200 km/h (61.8 lbf @ 125 mph)
Operating Frequency
- Worldwide: 5150-5875 MHz USA: U-NII-1: 5150-5250 MHz, U-NII-2-A: 5250-5350 MHz, U-NII-2C: 5470-5725 MHz, U-NII-3: 5725-5850 MHz
PoE
- Passive PoE (Pairs 4, 5+; 7, 8 Return)
LAN Port 10/100/1000
- (1) 10/100/1000 Ethernet Port
Power Supply
24 V, 0.3 A Gigabit PoE adapter (included)
Dimension
- 358 x 271.95 x 272.50 mm (14.09 x 10.71 x 10.73″)
الوزن
- Without Mount: 800 g (1.76 lb), With Mount 980 g (2.16 lb)
Max. Power Consumption
- 7W
Operating Temperature
- -40 to 70° C (-40 to 158° F)
