Image sensor: 1/3" Progressive Scan CMOS
Lens:
- 2.8-12mm, F1.4
- horizontal field of view: 108°~31°
Shutter speed: 1/3s~1/100 000s
Lens mount: M14
Min. illumination: Color: 0.01 lux, (F1.2, AGC ON), 0 lux with IR
Max. resolution: 2688x1520 (4Mpx)
Main stream:
- 50Hz: 20kl/s (2688x1520, 2304x1296)
- 50Hz: 25kl/s (1920x1080, 1280x720)
- 60Hz: 20kl/s (2688x1520, 2304x1296)
- 60Hz: 30kl/s (1920x1080, 1280x720)
Video bit rate: 32Kbps~16Mbps
1x slot microSD/SDHC/SDXC: 128GB
Interfaces:
- 1x RJ-45 10/100Mbps
- 1x video output: Vp-p composite output (75Ω/BNC)
Functions:
- 3D DNR
- true WDR: 120dB
- BLC
- Day/Night: IR cut filter with auto switch
ROI : support 1 fixed region
Detection:
- motion detection
Alarm trigger:
- video tampering alarm
- network disconnected
- IP address conflict
- full HDD
- error HDD
IR range: up to 30m
Protection level: IP67, IK10
Power:
- DC 12V, 5,5W
- PoE (802.3af)
Temperature of work: -30°C ~+60°C
Dimensions: 141x99,9mm

High quality and resolution, compact, 4 megapixel Hikvision camera.
Maximum resolution 2688×1520 pixels, 20 frames per second.
May be used as part of a video surveillance system or connected directly to PC/laptops/tablets or smartphones via network.
Compatible with Hikvison NVR video recorders
H.264 codec for high rate video compression, saves space and retains extra smooth quality of footage.
Night vision - up to 30m IR range. Switches on automatically under low-light or challenging lighting conditions.
Vari-focal lens: 2.8 - 12 mm., angle of view: 108° to 31°./Motorized Zoom Lens
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB.
Operating temperature -30 °C ~ 60 °C (-85 F ~ 140 F). Humidity 95% or less (non-condensing).
Complies with IP66 standard – fully protected from adverse weather conditions.
Dual stream function – useful for recording high-quality video while also transmitting the same pictures over a network with limited bandwidth.
120dB Wide Dynamic Range.
DC12V & PoE (a single Ethernet cable for power and connection to the network, so no additional power cables required - fast and easy installation)
